Webhooks

After a document has been signed it can be delivered back to your system.

Definition of terms

The following keys are needed to work with webhooks

  • companyKey the baseKey used to identify a company.
  • flowKey There can be many flows each with its own delivery methods registered.
  • apiKey The key used to validate that Taktikal sends the webhook data.

Webhook

The data Taktikal sends via webhook are wrapped in a WebhookEventPayload object that has an Id, EventData, and EventSignature See example data below.

  • EventSignature is used to validate that Taktikal is the one how sends the data. TimeStamp and GUID hashed with the apiKey to create a Signature. If the Signature that is calculated is not a match to the value in the event, it was not sent by Taktikal.
  • EventData contains all signee that signed the document and all their personal information provided in this process. The signed document is stored as a base64 string in the field SignedDocument

Taktikal will send a POST request to the registered URL when an event occurs and expects an HTTP Status code 200 Response. For all other response codes, Taktikal Will retry two more times. Unless an HTTP Status code 406 (not accepted) is received that marks that we will not try again.

Webhook event types

  1. SignedDocument This is an event that is run for each signing except the last one
  2. AllSigned This is an event triggered on the last sign on a process
  3. Auth This is an event that is run when user authenticates with e-id
  4. Signup Signup message event
  5. Canceled This is an event that is run when a signing process is canceled
  6. Expired Not all signees have signed within the time frame
  7. Reminder a reminder to sign a document

Register a webhook

Webhooks can be managed via the API. All routes can be viewed in Swagger here.

Code examples

Example webhook event

{
"Id": "3e9922f5fd7f4a9baa75a3fa90cb9caf",
"EventData": {
"Signees": [
{
"Name": "Test User",
"Ssn": "1234567890",
"PhoneNumber": "1234567",
"Email": "testUser@taktikal.is",
"Address": "Address 5",
"City": "Reykjavík",
"Key": "si67067e3aaa2c",
"Signed": true,
"ProcessKey": "spae707",
"CommunicationDeliveryType": "Email"
}
],
"FlowKey": "722989cac3fx",
"FlowName": "Umsókn um frí",
"SignedDocument": "JVBERi0xLjQ...",
"Attachments": [
{
"FileName": "auka_skjal.pdf",
"FileContent": "JVBE..."
},
{
"FileName": "auka_skjal_2.pdf",
"FileContent": "JVBER..."
},
{
"FileName": "mega skjal.pdf",
"FileContent": "JVBERi0x..."
}
],
"AttachmentReferences": [
{
"Id": "at73bb",
"FileName": "logo_4x.png",
"ContentLength": 9376,
"ContentType": "image/png",
"Url": "https://app.taktikal.is/attachment/sp30524e1d5d9b/at73bb/logo_4x.png",
"Description": "Description goes here"
},
{
"Id": "at8d9b",
"FileName": "large_file.zip",
"ContentLength": 6923449,
"ContentType": "application/zip",
"Url": "https://app.taktikal.is/attachment/sp30524e1d5d9b/at8d9b/large_file.zip",
"Description": "Description goes here"
}
],
"EventType": 2, // "AllSigned",
"Meta": {
"PdfUrl": "https://fill.dropandsign.is/api/flow/665a62b4a97a/pdf",
"PdfFieldData": "{\"Nafn\":\"Test User\",\"notendaheiti\":\"info\",\"Kennitala\":\"123456-7890\"}"
}
},
"EventSignature": {
"TimeStamp": 637030223561542290,
"Guid": "3e9922f5fd7f4a9baa75a3fa90cb9caf",
"Signature": "5qN29xaZHKZ65PLMB6ajRgpcxUU9dFRAXhkw36C2d38="
}
}

C# example

Data transfer objects to accept webhooks from Taktikal and a validation function.

using System;
using System.Collections.Generic;
using System.Security.Cryptography;
using System.Text;

namespace Webhook
{
public class WebhookEventPayload
{
public Guid Id { get; set; }
public SignedDocumentEventData EventData { get; set; }
public EventSignature EventSignature { get; set; }
}

/// <summary>
/// The signature section that will be in all webhook payloads. Used to validate the payload
/// </summary>
public class EventSignature
{
public long TimeStamp { get; set; }
public Guid Guid { get; set; }
public string Signature { get; set; }
}

public class SignedDocumentEventData
{
public List<Signee> Signees { get; set; }
public string SignedDocument { get; set; }
public List<SigningAttachment> Attachments { get; set; }
public EventType EventType { get; set; }
public Dictionary<string, string> Meta { get; set; }
}

public class SigningAttachment
{
public string FileName { get; set; }

/// <summary>
/// FileContent is stored as base64 string
/// </summary>
public string FileContent { get; set; }
}

public enum EventType
{
AllSigned
}

public class Signee
{
public string Name { get; set; }
public string Ssn { get; set; }
public string PhoneNumber { get; set; }
public string Email { get; set; }
public string Address { get; set; }
public string PostalCode { get; set; }
public string City { get; set; }
public string Key { get; set; }
public bool Signed { get; set; }
public string ProcessKey { get; set; }
public string CommunicationDeliveryType { get; set; }
}

public static class WebhookHelpers
{
/// <summary>
/// Creates a signature for a given timestamp and guid using a secret
/// </summary>
public static string GetSignature(long timestamp, Guid guid, string secret)
{
secret = secret ?? "";
var encoding = new UTF8Encoding();
byte[] keyByte = encoding.GetBytes(secret);
byte[] messageBytes = encoding.GetBytes($"{timestamp}{guid}");
using (var hmacsha256 = new HMACSHA256(keyByte))
{
byte[] hashmessage = hmacsha256.ComputeHash(messageBytes);
return Convert.ToBase64String(hashmessage);
}
}
}
}

JavaScript example (TypeScript)

// types
export interface Payload {
Id: string;
EventData: {
Signees: Signee[];
FlowKey: string;
FlowName: string;
SignedDocument: string;
Attachments: any[];
EventType: number;
Meta: {
pdfFieldData: string;
};
};
EventSignature: {
TimeStamp: number;
Guid: string;
Signature: string;
};
}

export interface Signee {
Name: string;
Ssn: string;
PhoneNumber: string;
Email: string;
Address: null;
PostalCode: null;
City: null;
Key: string;
Signed: boolean;
ProcessKey: string;
CommunicationDeliveryType: number;
}

// request handler
export const webhook: Handler = async (req, res) => {
try {
const { EventData } = req.body as Payload;
// save the data
res.status(200).json({ message: "OK" });
return;
} catch (e) {
res.status(400).json({ message: "error" });
return;
}
};
